Delta Modulation and Demodulation
Product Code : JA-CT-1503
Delta Modulation and Demodulation
Object:
To study delta modulation and demodulation.
Features:
The board consists of the following built-in parts :
5V D.C. at 100mA IC regulated power supply internally connected
±12V D.C. at 100mA IC regulated power supply internally connected
Quad Op-Amp IC
Two Up/Down counter IC
Digital to Analog convertor DAC IC
Quad two input NAND gate IC
Timer IC
Cooperator IC
Potentiometer for varying amplitude of modulating signal
Mains ON/OFF switch, fuse and jewel light
The unit is operative on 230V ±10% at 50Hz A.C. Mains
Adequate no. of patch cords stackable from rear both ends 4mm spring loaded plug length ½ metre
Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections /observation of waveforms
Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References
Weight : 3 Kg. (Approx.)
Dimension : W 340 x H 110 x D 210
Other Apparatus Required:
Cathode Ray Oscilloscope 20MHz
