Geoboard
Product Code : JL-LEP-10293
The Geoboard (SKU JL-LEP-10293) is a square and circle geoboard in blue plastic for work on polygons, circles, area, perimeter and circumference. The top surface has 25 guiding posts in a 5 x 5 square, 40 mm apart between centres. The underside is a circle geoboard with 12 posts set 30 degrees apart on a 150 mm circle plus one centre post. The board is about 200 x 200 mm, with 6 mm posts about 20 mm high. JaincoLab manufactures it in India, made as per DepEd guidelines.
Specifications
The geoboard is specified by its two surfaces, material and size: a 25-post 5 x 5 square (40 mm spacing) on top, a 13-post circle (12 posts at 30 degrees on 150 mm plus centre) below, blue plastic, about 200 x 200 mm.
| Product | Geoboard |
| SKU | JL-LEP-10293 |
| Top surface | Square geoboard, 25 posts in a 5 x 5 square, 40 mm between centres |
| Bottom surface | Circle geoboard, 13 posts: 12 at 30 degrees on a 150 mm circle plus 1 centre post |
| Material and colour | Plastic, blue |
| Board dimensions (W x L) | About 200 x 200 mm |
| Post diameter | About 6 mm |
| Post height | About 20 mm |
| Base height | About 25 mm |
| Board thickness | About 4 mm |
| Specification reference | As per DepEd guidelines |
Applications of the square and circle geoboard
The board is used for hands-on geometry, turning over between grid and circle work. Typical uses are:
- Building squares, rectangles and triangles on the 5 x 5 grid
- Finding area and perimeter in grid units
- Marking central angles of 30 degrees on the circle side
- Exploring radii, chords and regular polygons in a circle
Scope of supply
Each unit is one two-sided geoboard, as described in the specification table. Rubber bands are confirmed on the quotation, as are accessories, spares and quantities.
Packing, MOQ and lead time
Minimum order quantity, packing and lead time are confirmed on the quotation for the quantity and destination. JaincoLab supplies class sets for schools, bulk orders for education projects, and export shipments to Africa, the Middle East and South and South-East Asia.
Frequently asked questions
What is on each side of this Geoboard?
A 25-post 5 x 5 square geoboard on top and a 13-post circle geoboard underneath.
How far apart are the square posts?
40 mm between centres.
What size is the board?
About 200 x 200 mm, in blue plastic.
What should a quotation request include?
Send the SKU JL-LEP-10293, the quantity and the delivery destination.
Related products
Related geometry aids:
Browse Laboratory Equipment Products or the range from JaincoLab as a maths lab equipment manufacturer in India.
Request a quote
To order the Geoboard, send the quantity and delivery destination through the JaincoLab contact page or email [email protected].
