High-Efficiency Switching Power Supply Unit of 15 A
Product Code : JA-PLE-4266
The High-Efficiency Switching Power Supply Unit of 15 A (SKU JA-PLE-4266) is a compact, fan-cooled DC supply with a variable 9-17 V output, rated at 13 A operating and 15 A maximum current. It accepts a selectable 100-260 V AC input and is protected against short circuit and overvoltage, with a warning LED. This 15 A switching power supply is used in physics and electronics laboratories to run apparatus that needs a heavy low-voltage DC current.
Specifications
The unit gives 9-17 V DC (variable) at 13 A operating and 15 A maximum current with 17 mV ripple and noise, from a 100-260 V AC selectable input, in a 165 x 55 x 150 mm case weighing 0.6 kg.
| Product | High-Efficiency Switching Power Supply Unit of 15 A |
| SKU | JA-PLE-4266 |
| AC input | 100-260 V, selectable |
| DC output | 9-17 V, variable |
| Operating current | 13 A |
| Maximum current | 15 A |
| Ripple and noise | 17 mV |
| Protection | Short circuit and overvoltage, with warning LED |
| Cooling | Fan |
| Indicators | LED showing unit on |
| Fuse | 220 V / 3 A |
| Dimensions | 165 x 55 x 150 mm |
| Weight | 0.6 kg |
Applications of the 15 A switching power supply
A 9-17 V supply that can deliver up to 15 A is suited to apparatus that draws heavy current at low voltage, such as electromagnets, coils, motors and lamp arrays, where an ordinary 2-5 A bench supply would be overloaded.
- Powering electromagnets, solenoids and large coils
- Running DC motors and motor-generator demonstrations
- Supplying lamp arrays and heating-element experiments
- Replacing accumulators as a steady heavy-current DC source
- Physics, electronics and TVET electrical laboratories
Scope of supply and ordering
The listing covers the switching power supply unit with its fan cooling, protection and indicators. Leads and connected apparatus are separate items. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing are confirmed on each quotation according to the number of units and the delivery destination. JaincoLab supplies school and college laboratories, bulk education-project orders and export consignments to buyers in Africa, the Middle East and South and South-East Asia.
Frequently asked questions
What output does the switching power supply give?
A variable 9-17 V DC output, 13 A operating and 15 A maximum.
What mains input can it take?
A selectable AC input from 100 V to 260 V.
Is it protected?
Yes. It has short-circuit and overvoltage protection with a warning LED, and is fan cooled.
