Joints, Cone with Tip
Product Code : JA-SDAJ-1677
Joints, Cone with Tip (product code JA-SDAJ-1677) are ground-glass cones that end in a tip below the ground section. A cone joint with tip is used by glassblowers on apparatus where liquid runs out through the cone, such as the lower end of a condenser or the stem of a dropping funnel, because the tip guides drops away from the joint and into the vessel below. Ten cone sizes are listed, B10 to B55, all on a 90 mm shank.
Specifications
These cone joints have a 90 mm shank and a tip beyond the cone, and are listed in 10 sizes from B10 to B55. Each cone fits a socket with the same B number.
| Product | Joints, Cone with Tip |
| SKU / Product code | JA-SDAJ-1677 |
| Type | Joint, cone with tip |
| Shank length | 90 mm |
| Cone sizes | B10, B14, B19, B24, B29, B34, B40, B45, B50, B55 |
Applications of the cone joint with tip
The tip keeps returning or dispensed liquid off the ground surface of the joint, which helps the joint stay clean and seal well.
- Lower cones of reflux condensers
- Stems of dropping and separating funnels
- Outlets of receivers and adapters that deliver liquid
- Glassblowing repairs and custom apparatus
Scope of supply
The listing covers cone joints with tip in the sizes and quantities you order. Sockets, clips, accessories, spares and quantities are confirmed on the quotation.
Packing, MOQ and lead time
MOQ, lead time and packing are confirmed on each quotation for quantity and destination. JaincoLab supplies glassblowing workshops, single laboratories, bulk orders for institutes, and export orders to Africa, the Middle East and South and South-East Asia.
Frequently asked questions
Which cone sizes are listed?
B10, B14, B19, B24, B29, B34, B40, B45, B50 and B55, all with a 90 mm shank.
What is the tip for?
It guides liquid away from the ground section into the vessel below.
Is a plain cone joint available?
Yes. Joints, Cone, Single are listed with a 110 mm shank from B7 to B55.
What should a quotation request include?
Send the product code JA-SDAJ-1677, the cone sizes and quantity of each, and the delivery destination.
Related products
Other joints and fittings in the same category:
See the full Screwthreads, Discs and Joints category, part of the range from JaincoLab, a laboratory glassware manufacturer in India.
Request a quote
To order Joints, Cone with Tip, send the cone sizes, quantities and delivery destination through the JaincoLab contact page or email [email protected].
