Multimeter Digital
Product Code : JL-LEP-10420
The Multimeter Digital (SKU JL-LEP-10420) is a 6000-count, auto-ranging digital multimeter that reads AC and DC voltage and current, resistance, capacitance, frequency, duty cycle and temperature. This digital multimeter covers DC voltage up to 1000 V, current up to 10 A, resistance up to 60 megohm and capacitance from 10 nF to 100 mF, which suits both school circuit work and college electronics. JaincoLab supplies it to laboratories and training centres.
Specifications
The digital multimeter has a 6000-count auto-ranging display with DC voltage from 60 mV to 1000 V, AC voltage to 750 V, AC and DC current from 600 µA to 10 A, resistance from 600 ohm to 60 megohm, capacitance from 10 nF to 100 mF, frequency to 10 MHz, duty cycle and temperature from -20 to 1000°C.
| Product | Multimeter Digital |
| SKU | JL-LEP-10420 |
| Purpose | Digital readout of AC and DC current and voltage, resistance, capacitance and frequency |
| DC voltage | 60 mV, 6 V, 60 V, 600 V, 1000 V; ±(0.7% + 2) |
| AC voltage | 600 mV, 6 V, 60 V, 600 V, 750 V; ±(0.8% + 3) |
| DC current | 600 µA, 6000 µA, 60 mA, 600 mA ±(1.2% + 3); 6 A, 10 A ±(2.0% + 10) |
| AC current | 600 µA, 6000 µA, 60 mA, 600 mA ±(1.5% + 3); 6 A, 10 A ±(3.0% + 10) |
| Resistance | 600 ohm, 6 kilohm, 60 kilohm, 600 kilohm, 6 megohm, 60 megohm; ±(1.2% + 5) |
| Capacitance | 10 nF to 100 mF in eight ranges; ±(3.0% + 3) |
| Frequency | 10 Hz to 10 MHz in seven ranges; ±(1.0% + 5) |
| Duty cycle | 0.1% to 99.99%; ±(3.0% + 2) |
| Temperature | -20 to 1000°C (-4 to 1832°F) |
| Display | 6000 counts, auto range |
| Specification reference | As per DepEd guidelines |
Applications of the digital multimeter
The meter is the general measuring instrument of the electricity and electronics laboratory, used by students to check circuits and components and by technicians to test equipment.
- Measuring voltage, current and resistance in school circuit practicals
- Checking resistors and capacitors in electronics projects
- Measuring frequency and duty cycle of signals in college electronics
- Taking readings on the built-in temperature range in heat experiments
- Fault finding and equipment testing in TVET electrical and electronics courses
Scope of supply
The listing covers one 6000-count digital multimeter as described in the specification table. Test leads, temperature probe, battery and quantities are confirmed on the quotation.
Packing, MOQ and lead time
Minimum order quantity, lead time and packing are quoted for the number of meters and the delivery destination. JaincoLab supplies laboratories, colleges, TVET centres and export buyers in Africa, the Middle East and South and South-East Asia.
JaincoLab supports tender contractors as well as institutions: we manufacture and export laboratory equipment for Ministry of Education projects, World Bank-funded tenders and United Nations programmes, executed successfully in many countries, and we specialise in turnkey laboratory set-ups. Contact us through the tenders page early in your bid preparation.
Frequently asked questions
What does the digital multimeter measure?
AC and DC voltage and current, resistance, capacitance, frequency, duty cycle and temperature.
What is the display?
6000 counts with auto range.
What are the maximum voltage and current ranges?
1000 V DC, 750 V AC and 10 A AC or DC.
What resistance range does it cover?
600 ohm to 60 megohm, with ±(1.2% + 5) accuracy.
What should a quotation request include?
Send the SKU JL-LEP-10420, the number of meters and the delivery destination.
