Prism Set
Product Code : JL-LEP-10354
The Prism Set (SKU JL-LEP-10354) is an acrylic prism set of three solid optical blocks, a rectangular block, a right-angle prism and a semi-circular block, each frosted on one side, for demonstrating the refraction of light. Students trace rays through the blocks to measure angles of incidence and refraction and to observe total internal reflection. JaincoLab manufactures the set in India for school and college physics laboratories.
Specifications
The acrylic prism set contains three solid acrylic pieces, each frosted on one side: a rectangular block 70 mm long, 50 mm wide and at least 20 mm thick, a right-angle prism at least 10 mm thick with a 40 mm base and 65 mm height, and a semi-circular block 100 mm in diameter and 10 mm thick.
| Product | Prism Set |
| SKU | JL-LEP-10354 |
| Purpose | Demonstrates characteristics of refraction of light |
| Rectangular block | 1 piece, solid acrylic, frosted on one side; 70 mm long, 50 mm wide, 20 mm thick minimum |
| Right-angle prism | 1 piece, solid acrylic, frosted on one side; thickness 10 mm minimum, base 40 mm minimum, height 65 mm minimum |
| Semi-circular block | 1 piece, solid acrylic, frosted on one side; 100 mm diameter, 10 mm thick |
| Specification reference | As per DepEd guidelines |
Applications of the acrylic prism set
The prism set is used for ray-tracing practicals in which a narrow beam is shone through each block on paper, so students can mark the incident and emergent rays, measure angles and relate them to the refractive index of acrylic.
- Tracing refraction through the rectangular block and measuring lateral displacement
- Finding the refractive index of acrylic from angles of incidence and refraction
- Showing total internal reflection and the critical angle with the semi-circular block
- Using the right-angle prism to turn a ray through 90 or 180 degrees
- Refraction practicals in secondary science and senior secondary physics
Scope of supply
The listing covers the rectangular block, right-angle prism and semi-circular block described in the specification table. Ray boxes or light sources, accessories, spares and quantities are confirmed on the quotation.
Packing, MOQ and lead time
MOQ, lead time and packing are confirmed on the quotation for the number of sets and the delivery destination. We supply single physics laboratories, school and college bulk orders, and export buyers in Africa, the Middle East and South and South-East Asia.
Turnkey laboratory projects are a JaincoLab specialism. We manufacture and export equipment for education-ministry programmes, World Bank tenders and United Nations projects, with successful deliveries in many countries. If you are bidding for a similar tender, share the bill of quantities through our tenders page.
Frequently asked questions
Which pieces are in the prism set?
A rectangular block, a right-angle prism and a semi-circular block.
What are the block sizes?
The rectangular block is 70 mm × 50 mm and at least 20 mm thick; the right-angle prism is at least 10 mm thick with a 40 mm base and 65 mm height; the semi-circular block is 100 mm in diameter and 10 mm thick.
What material are the blocks made of?
All three pieces are solid acrylic, frosted on one side.
What should a quotation request include?
Send the SKU JL-LEP-10354, the number of sets and the delivery destination.
